Protection at the Front Door: Why Fire-Rated Doors Matter
Critical Protection in a Fire
During a structure fire, seconds matter. Flames spread quickly, smoke fills spaces, and heat can become unbearable in moments. A fire-rated entry door can make all the difference—slowing the spread of flames, blocking dangerous smoke, and providing valuable time to escape safely.
Fire-rated doors are required in many settings: apartment units, stairwells, garage-to-home entryways, and between building sections in both residential and commercial properties. At Studio 4 Showroom, we offer ProVia’s tested fire-rated doors that combine life-saving protection with lasting durability and design flexibility.
How Fire-Rated Doors Work
Fire-rated doors are designed and tested to withstand extreme heat—over 1400°F—for 20 to 90 minutes depending on the model. This delay helps contain fire and smoke, keeping escape routes clear and reducing property damage.
Required Components for Protection:
Self-closing & self-latching hardware – ensures the door seals shut in an emergency.
Spring Bommer hinges or closers – allow automatic closure.
Q-Lon® fire-rated weatherstripping – blocks smoke and heat.
Positive pressure tested construction – resists force from fire and heat.
ProVia Fire-Rated Door Options
At Studio 4, we offer both steel and fiberglass fire-rated doors in residential and non-residential applications.
🔒 90-Minute Fire-Rated Doors
Residential: Legacy 20-gauge & 24-gauge steel with steel frame
Non-Residential: Legacy 20-gauge steel with steel frame
🔒 20-Minute Fire-Rated Doors
Residential & Non-Res: Legacy 20-gauge steel with steel, wood, or composite frame
Residential & Non-Res: Signet fiberglass in Cherry, Mahogany, Oak, or Smooth skins; available in door styles 001, 002-440, 002C-449, 003, 006
⚠️ Note: Fire rating applies to single doors only (no double or French doors).
Specs & Hardware Requirements
To meet safety standards, ProVia fire-rated doors follow strict guidelines:
Max door size: 36" x 84" (some custom sizing available)
Max glass size: 100 sq. inches
Frame options: Wood, PermaTech™, or Steel
Thresholds: Z-AC, ADA, or saddle (varies by frame). Threshold optional—bottom margin must be ≤ ¾”
Not permitted: Kick-down stops, push/pull hardware, hold-open closers
Optional features: ProVia-certified hardware, 7/8" peephole, panic hardware (commercial)
Why Choose Studio 4 Showroom?
At Studio 4, we know safety and style go hand in hand. That’s why we recommend ProVia fire-rated doors—designed to meet building codes while offering customizable options for any entryway. Whether you need the strength of steel or the warmth of wood-look fiberglass, we’ll help you select the perfect fire-rated entry door for your project.
👉 For full specifications, labeling requirements, and testing information, contact us today—or stop by our showroom to see these doors in person.
